ITEM DESCRIPTION
Standard load:
Maximum door weight 200 kg (per pair)Application:
Concealed hinge for non-rebated doors, hinge leaves are mortised into frame and door; 3-dimensional adjustability, maintenance-free bearings; suitable for claddingsAccessories:
PIVOTA ® DX safety plate for frame part, retainer for casing or steel framesItem number | Finish |
039253 | Alu Look F1 |
040588 | Edelstahl Look |
037979 | velour vernick. |
