ITEM DESCRIPTION

Standard load:

Maximum door weight 160 kg (per pair)


Application:

Concealed hinge for non-rebated doors, hinge leaves are mortised into frame and door; 3-dimensional adjustability, maintenance-free bearings; suitable for claddings


Accessories:

PIVOTA ® DX safety plate for frame part, retainer for casing or steel frames Note: also available in "Design"-option

Item number	Finish
040607	Edelstahl Look
040711	Alu Look F1
039886	velour vernick.
